Description
Artesian Pro Pump is the right choice for your higher flow applications. This pump delivers efficient operation and superior flow rates. Enjoy the safety and convenience of a self-priming unit along with excellent energy savings. Features a large strainer basket and an easy open transparent lid. The uniquely designed lid and clamp ring insure a proper seal with minimal o-ring wear. Experience the difference for yourself.
1 HP
13500 GPH
Specifications:
| Model | AP 1-HF |
| HP | 1 |
| TYPE | 10 ODP |
| RPM | 3450 |
| Voltage | 115/230 |
| HZ | 60 |
| Max Watts/Amps | 1780/7.9 |
| Amps @ 230V @ Max. Head* | 4.1 @ 45ft. |
| Amps @ 230V @ Max. Flow* | 6.9 @ 13,500 GPH @ 7' |
*Watt and Amp draw rating are typical, but can vary with different motors and operating voltages.
3 HP
17820 GPH
Specifications:
| Model | AP 3-HF |
| HP | 3 |
| TYPE | 10 ODP |
| RPM | 3450 |
| Voltage | 208-230 |
| HZ | 60 |
| Max Watts/Amps | 3100/13.4 |
| Amps @ 230V @ Max. Head* | 6.7 @ 58ft. |
| Amps @ 230V @ Max. Flow* | 13.1 @ 17,820 GPH @ 13' |
*Watt and Amp draw rating are typical, but can vary with different motors and operating voltages.
5 HP
19740 GPH
Specifications:
| Model | AP 5-HF |
| HP | 5 |
| TYPE | 10 ODP |
| RPM | 3450 |
| Voltage | 208-230 |
| HZ | 60 |
| Max Watts/Amps | 4000/17.6 |
| Amps @ 230V @ Max. Head* | 9.5 @ 68ft. |
| Amps @ 230V @ Max. Flow* | 17.3 @ 19,740 GPH @ 15' |
*Watt and Amp draw rating are typical, but can vary with different motors and operating voltages.
