Name: ArtesianPro High Flow Pumps
SKU: 153782

Description

Artesian Pro Pump is the right choice for your higher flow applications. This pump delivers efficient operation and superior flow rates. Enjoy the safety and convenience of a self-priming unit along with excellent energy savings. Features a large strainer basket and an easy open transparent lid. The uniquely designed lid and clamp ring insure a proper seal with minimal o-ring wear. Experience the difference for yourself.

Money saving, high efficiency pump and motor units.

Quick disconnect unions are included.

Corrosion-resistant polyproylene housing.

Long life corrosion resistant Stainless Steel shaft seals.

Pump performance can be easily altered with multiple impeller interchangeability options.

External out of water pumps help protect your investment from potentially dangerous oil leaks and electrical hazards.

Designed to operate at any point on specifies performance curve

Minimum recommended continuous flow rate of five gallons per minute

3 inch suction and discharge ports with quick connect fittings included

316 stainless steel shaft seal

3 year limited warranty (for fresh water applications)

Made with care in USA

1 HP

13500 GPH

Specifications:

Model	AP 1-HF
HP	1
TYPE	10 ODP
RPM	3450
Voltage	115/230
HZ	60
Max Watts/Amps	1780/7.9
Amps @ 230V @ Max. Head*	4.1 @ 45ft.
Amps @ 230V @ Max. Flow*	6.9 @ 13,500 GPH @ 7'

*Watt and Amp draw rating are typical, but can vary with different motors and operating voltages.

This product is oversized - special shipping rates may apply.

3 HP

17820 GPH

Specifications:

Model	AP 3-HF
HP	3
TYPE	10 ODP
RPM	3450
Voltage	208-230
HZ	60
Max Watts/Amps	3100/13.4
Amps @ 230V @ Max. Head*	6.7 @ 58ft.
Amps @ 230V @ Max. Flow*	13.1 @ 17,820 GPH @ 13'

*Watt and Amp draw rating are typical, but can vary with different motors and operating voltages.

5 HP

19740 GPH

Specifications:

Model	AP 5-HF
HP	5
TYPE	10 ODP
RPM	3450
Voltage	208-230
HZ	60
Max Watts/Amps	4000/17.6
Amps @ 230V @ Max. Head*	9.5 @ 68ft.
Amps @ 230V @ Max. Flow*	17.3 @ 19,740 GPH @ 15'
